Gigabyte H270-F4G (rev. 100) [17/125] 1 system components

Hardware Installation - 17 -

Item Decription

Power module

2. Power supply board cage

3. PCI Express card

4. Fan duct

5. Memory module

6. System cooling fan

7. Hard drive

2-1 System Components
