Gigabyte H270-F4G (rev. 100) [31/125] Chapter 3 system appearance

- 31 - Hardware Installation

Chapter 3 System Appearance

3-1 Front View

No. Decription

ID button and LED

2. Power button and status LED

3. VGA port

4. USB 3.0 ports

5. HDD bays

NOTE! For detail LED description, please see the following section:

Front Panel LED and Buttons and Rear System Button and LEDs.

1 23

4 21
