- 13 - Hardware Installation
Rear Panel I/O w 2 x USB 2.0/3.0 ports
w 1 x 10/100/1000 Management LAN port
w 2 x RJ-45 ports (H270-H70 Only)
w 1 x QSFP+ LAN port (H270-F4G Only)
w 1 x Serial port
w 1 x VGA port
w 1 x Power switch button/status LED
w 1 x ID switch button/LED
w 1 x Reset button
w 1 x NMI button
w 1 x System status LED
w 2 x LAN Link/Active LED (LAN1/LAN2)
Front Panel
LED/Buttons
w 1 x Power button/System status LED
w 1 x ID button/LED
w 2 x USB3.0/2.0 ports
w 1 x VGA port
I/O Controller w ASPEED
®
AST2400 BMC chip
Hardware
Monitor
w System voltage detection
w CPU/System temperature detection
BIOS w 1 x 128 Mbit ash
w AMI BIOS
Environment
Ambient
Temperature
Relative
Humidity
w Operating Temperature: 10
o
C to 35
o
C
w Non-operating Temperature: -40
o
C to 60
o
C
w Operating humidity: 8-80% (non-condensing)
w Non-operating humidity: 20%-95% (non-condensing)
System
Dimension
w 447Wx87.2Hx780D (mm)
Electrical
Power Supply
w 2 x Hot-plug 1U PSU 1600W at 80 plus Platinum level
w AC input 100-127V: DC Output 1000W Max
w AC input 200-240V: DC Output 1600W Max
* GIGABYTE reserves the right to make any changes to the product specifications and product-related information
without prior notice.
