M8
166 167
Italiano
Windows:
Ci sono sei funzioni principali prima di accedere al sistema operativo.
• LogoM8/Dataeora:
Dopo avere visualizzato il logo per dieci secondi, lo schermo mostra la data e
l'ora.
Il display si spegne se è lasciato inattivo per cinque minuti.
• Volume:
Permette di aumentare/diminuire il livello del volume girando la manopola
verso destra/sinistra.
• Mode(Modalità):
Permette di passare fra tre modalità di risparmio energetico – Eco, Standard o
Speed (Velocità).
• Info:
Permette di passare tra vari tipi di informazioni critiche per controllare lo stato
del sistema. Il display OLED mostra la frequenza della CPU, l'utilizzo della CPU,
l'utilizzo della LAN o i dati APM*.
*APM (Actions Per Minute) misura il numero di azioni tastiera/mouse eseguite
in un minuto. Per scoprire quanto velocemente possono muoversi le dita,
premere una volta la manopola A-Command per avviare il conteggio APM.
Premere di nuovo la manopola A-Command per arrestare il conteggio.
• Light(Luce):
Attivare/disattivare la luce del case, oppure abilitare la funzione Good Night
LED*.
On (Attiva): Attiva la luce del case
O (Disattiva): Disattiva la luce del case
All o (Disattiva tutto): Disattiva la luce del case; abilita la funzione Good Night
LED.
*La tecnologia ASRock Good Night LED ore un migliore ambiente per
dormire spegnendo i LED non essenziali. Abilitando Good Night LED, i LED
alimentazione/HDD si spengono quando il sistema è acceso. La funzione Good
Night LED spegne automaticamente i LED alimentazione e della tastiera quando
il sistema accede alla modalità di standby/ibernazione.
• Time(Ora):
Permette di attivare/disattivare l’ora.
Se questa opzione è impostata su On (Attiva), il logo M8 / Data e ora sono
visibili. Se questa opzione è impostata su O (Disattiva), il logo M8 / Data e ora
sono nascosti.
