1.2 Especicaciones del producto
Color
•
Negro tormenta
Material
•
Estructura de acero / Aluminio + Plástico
Dimensiones
•
372 mm (AN) X 123 mm (AL) X 400 mm (LA)
Placa base
•
ASRock Z87-M8
CPU
•
Admite la familia de procesadores Intel® Core
TM
i7 / i5 / i3
/ Xeon® / Pentium® / Celeron® de la 4ª generación
Memoria
•
Admite DDR3 1600/1333/1066 MHz, 2 ranuras SO-DIMM
y una capacidad de hasta 16 GB
VGA
•
Admite 1 tarjeta gráca de doble ranura
Unidad óptica
•
1 x Unidad multiformato de inserción automática plana
Disco duro
•
Admite una unidad de disco duro de 3,5" y una de 2,5"
WiFi + BT
•
2T2R WiFi 802.11ac + BT v4.0
E/S frontal
•
4 x USB 3.0, 1 x Micrófono, 1 x Auricular
•
Lector de tarjetas 4 en 1 (SD3.0/MMC/MS/MS PRO)
E/S en panel
posterior
•
1 x Audio HD 7.1 con Creative Sound Core3D,
•
1 x LAN Intel Gigabit, 4 x USB3.0, 4 x USB2.0,
•
1 x eSATA2, 1 x DP, 1 x HDMI
Botón OLED
todo en uno
•
A-Command
Refrigeración
•
Superior: 2 ventiladores de 70 mm. Inferior: 2 ventiladores
de 70 mm
Fuente de
alimentación
•
Fuente de alimentación SFX de 450 W
