2.1.1 A função do A-Command
O A-Command é um botão controlador multifunções que é utilizado para percorrer
as diversas funções.
Controlar o A-Command
• Rode o o botão para alternar entre as funções principais ou opções.
• Prima uma vez para conrmar a sua selecção.
Ligar o sistema
Prima o botão A-Command para ligar o sistema. Aguarde que o sistema operativo
carregue automaticamente.
Desligar o sistema
Quando o visor OLED mostrar o logótipo M8 Logo / data e hora, prima o botão
A-Command e seleccione "Yes" (Sim) para desligar o sistema.
Antes de entrar no Windows
Existem três funções principais antes de entrar no SO.
• LogótipoM8/Dataehora:
Após a exibição do logótipo durante dez segundos, o visor exibirá a data e hora.
O visor irá desligar se estiver inactivo durante cinco segundos.
• Luz:
Ligar/desligar a luz da caixa.
• Hora:
Activar/desactivar a exibição da hora.
Se esta opção estiver activada, o visor apresentará o logótipo M8 / Data e hora.
Se esta opção estiver desactivada, o visor não apresentará o logótipo M8 / Data e
hora.
