M8
PB 1
English
Chapter 1 Introduction
ank you for purchasing M8, a reliable gaming barebone system produced under
ASRock’s consistently stringent quality control. It delivers excellent performance
with robust design conforming to ASRock’s commitment to quality and endurance.
1.1 Package Contents
•
M8 Barebone System with:
M8 Chassis
Mini-ITX Motherboard (pre-installed)
Power Supply Unit (pre-installed)
System Fan (pre-installed)
•
AC Power Cable
•
Hexagon Screwdriver
•
Screwdriver Set
•
Screw Package
•
System Key
•
VGA Support
•
6 x SATA Cable
•
Support CD
•
Quick Installation Guide
•
User Manual
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice. In case any modications of this documentation
occur, the updated version will be available on ASRock’s website without further notice. If
you require technical support related to this product, please visit our website for specic
information about the model you are using. ASRock website: http://www.asrock.com.
If any items are missing or appear damaged, contact your authorized dealer.
