Chapter 3 Hardware Installation
is chapter helps you assemble the chassis and install components. Please follow
the installation procedures listed below.
Installation Procedures
Removing the side panels
Removing the top cover
Removing the VGA card holder
Removing the riser card
Installing the hard drives
Installing the CPU
Installing the CPU Fan and CPU Cooler
Installing Memory Modules (SO-DIMM)
Replace the riser card
Installing the graphics card
Replace the VGA card holder
Replacing the side panels
Replacing the top cover
Aer making sure that you have properly connected the power supply and all the
necessary peripherals, power on the system.
1
2
3
4
5
6
7
8
9
10
11
12
13
