ASRock M8 Series [7/227] Product specifications
![ASRock M8 Series [7/227] Product specifications](/views2/1692972/page7/bg7.png)
2 3
English
1.2 Product Specications
Color
•
Storm Black
Material
•
Steel Body / Aluminum + Plastic
Dimension
•
372mm (W) x 123mm (H) x 400mm (L)
Motherboard
•
ASRock Z87-M8
CPU
•
Supports 4
th
Gen Intel® Core
TM
i7 / i5 / i3 / Xeon® /
Pentium® / Celeron® Processor Family
Memory
•
Supports DDR3 1600/1333/1066 MHz, 2 x SO-DIMM
slots, Max. up to 16GB
VGA
•
Supports 1 x Dual-slot Graphics Card*
Optical Drive
•
1 x Slim Slot-in Super-Multi Drive
Hard Disk
•
Supports 3.5"HDD and 2.5"HDD
WiFi + BT
•
2T2R WiFi 802.11ac + BT v4.0
Front I/O
•
4 x USB 3.0, 1 x MIC, 1 x Headphone
•
4-in-1 Card reader (SD3.0/MMC/MS/MS PRO)
Rear I/O
•
1 x 7.1HD audio with Creative Sound Core3D,
•
1 x Intel Gigabit LAN, 4 x USB3.0, 4 x USB2.0,
•
1 x eSATA2, 1 x DP, 1 x HDMI
All-In-One
OLED Button
•
A-Command
Cooling
•
Top : 2 x 70mm fan, Bottom : 2 x 70mm fan
Power Supply
•
SFX PSU 450W
