210 211
한국어
번호 설명 번호 설명
1 라인 입력 포트 ( 담청색 ) 10 eSATA2 포트 **
2 라인 출력 포트 ( 라임색 ) 11 DisplayPort
3 센터 / 서브우퍼 포트 ( 주황색 ) 12 HDMI 포트
4 후면 스피커 출력 포트 ( 검정 ) 13 USB3.0 포트
5 LAN RJ-45 포트 * (Intel Gigabit LAN) 14 USB3.0 포트
6 USB2.0 포트 15 USB3.0 포트
7 USB2.0 포트 16 USB3.0 포트
8 USB2.0 포트 17 광학 SPDIF 출력 포트
9 USB2.0 포트 18 마이크 포트 ( 분홍 )
* LAN 포트에는 LED 가 두 개가 있습니다 . LAN 포트 LED 지시 정보에 대해서는 아래 표를 참조하십시오 .
Activity / Link LED Speed LED
상태 설명 상태 설명
꺼짐 연결 안 됨 꺼짐 10Mbps 연결
점멸 데이터 동작 주황색 100Mbps 연결
켜짐 연결 녹색 1Gbps 연결
** eSATA 커넥터는 SATA3_4 커넥터와 공유됩니다 .
ACT/LINK LED
SPEED LED
LAN 포트
