ASRock IMB-A182P [19/39] System panel header

System Panel Header

(9-pin PANEL1)

(see p.8, No. 17)

This header accommodates

several system front panel

functions.

Connect the power switch, reset switch and system status indica-

tor on the chassis to this header according to the pin assignments

below. Note the positive and negative pins before connecting the

cables.

PWRBTN (Power Switch):

Connect to the power switch on the chassis front panel. You may

congurethewaytoturnoffyoursystemusingthepowerswitch.

RESET (Reset Switch):

Connect to the reset switch on the chassis front panel. Press the

reset switch to restart the computer if the computer freezes and

fails to perform a normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel.

The LED is on when the system is operating. The LED keeps

blinking when the sys-tem is in S1/S3 sleep state. The LED is off

when the system is in S4 sleep state or powered off (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel.

The LED is on when the hard drive is reading or writing data.

The front panel design may differ by chassis. A front panel mod-

ule mainly consists of power switch, reset switch, power LED,

hard drive activity LED, speaker and etc. When connecting your

chassis front panel module to this header, make sure the wire as-

signments and the pin assign-ments are matched correctly.

GND RESET#

PWRBTN#

PLED-

PLED+

GND

HDLED-

HDLED+

GND
