1 :
LVDS Power (VDD Power) Jumper
2 : Panel Backlight Power Jumper
3 : COM Port Pin9/Power Setting Jumpers (For COM1, COM3)
4 : Backlight Control Signal Setting Header
5
: Inverter Power/Control Header
6 : Panel Backlight & Audio AMP Volume Control Header
7 :
4-Pin CPU FAN Connector (+12V)
8 : ATX Power Connector (Input 12V)
9 :
20-pin ATX Power Input Connector
1
0 : SATA Power Output Connector
11 : SATA3 Connector (SATA_1)
12 :
USB2.0 Connectors (USB2_3, USB4_5)
13 :
4-Pin CPU FAN Connector (+12V)
14 : Digital Input/Output Pin Header
15:JGPIO_SET1
16 : ATX/AT Mode Jumper
17 :
System Panel Header
18 : COM Port Pin9/Power Setting Jumpers (For COM2, COM4)
19 : COM Port Headers (RS232) (COM2, COM4, COM5, COM6)
20 : Digital Input/Output Power Select
21 : Chassis Intrusion Headers
22 : Printer Port Header
23 : LPC Header
24 : Clear CMOS Header
25 : Power Loss Jumper
26 :
Front Panel Audio Header
27 : SPDIF Header
28 : 3W Audio AMP Output Wafer
29 : LVDS Panel Connector
