ASRock D1541D4I [16/84] English
![ASRock D1541D4I [16/84] English](/views2/1694224/page16/bg10.png)
10 11
English
No. Description
1
PSU SMBus (PSU_SMB1)
2
DC-IN 12V Power Connector (ATX12V1)*
3
ATX Power Connector (ATXPWR1)*
4
Front Fan Connector (FRNT_FAN1)
5
2 x 288-pin DDR4 DIMM Slots (CH0_A1, CH1_B1)
6
2 x 288-pin DDR4 DIMM Slots (CH0_A2, CH1_B2)
7
CPU Fan Connector (CPU_FAN1)
8
HDD Power Connector (HDD_PWR1)
9
TPM Header (TPM1)
10
USB 2.0 Header (USB_1)
11
Non Maskable Interrupt Button (NMI_BTN1)
12
Auxiliary Panel Header (AUX_PANEL1)
13
SATA DOM Power Jumper (SATAPWR1)
14
SATA3 Connector (SATA_4)
15
SATA SGPIO Connector (SATA_SGPIO1)
16
SATA3 Connector (SATA_5)
17
Speaker Header (SPEAKER1)
18
System Panel Header (PANEL1)
19
Front Fan Connector (FRNT_FAN2)
20
Intelligent Platform Management Bus header (IPMB_1)
21
COM Port Header (COM1)
22
BMC SMB Header (BMC_SMB1)
23
Mini SAS Connector (SATA_0_3)
24
ermal Sensor Header (TR1)
25
Chassis ID Jumper (CHASSIS_ID1)
26
ME Recovery Jumper (ME_RECOVERY1)
27
Rear Fan Connector (REAR_FAN1)
28
CPU PECI Mode Jumper (PECI1)
*Please use either the DC-IN 12V Power Connector (ATX12V1) or the ATX Power Connector (ATXPWR1) at one
time. Do not connect them both simutaneously.
