1.2 Specications
D1521D4I / D1541D4I / D1541D4I-2L2T
MB Physical Status
Form Factor Mini-ITX
Dimension 6.7'' x 6.7'' (17.02 cm x 17.02 cm)
Processor System
CPU Supports Intel® Xeon® D1541 / D1521 Processor
Chipset Soc
System Memory
Capacity - 4x DDR4 DIMM slots
- Supports up to 128GB DDR4 ECC RDIMM
- Supports up to 64GB DDR4 ECC/non-ECC UDIMM
DIMM Sizes and
Type per DIMM
- Non-ECC UDIMM :4GB, 8GB, 16GB
- ECC UDIMM : 4GB, 8GB, 16GB
- RDIMM : 4GB, 8GB, 16GB,32GB
Frequency D1521D4I:
- Non-ECC UDIMM : 1600, 1866, 2133MHz
- ECC UDIMM : 1600, 1866, 2133MHz
- RDIMM : 1600, 1866, 2133MHz
D1541D4I / D1541D4I-2L2T:
- Non-ECC UDIMM : 1600, 1866, 2133MHz, 2400MHz
- ECC UDIMM : 1600, 1866, 2133MHz, 2400MHz
- RDIMM : 1600, 1866, 2133MHz, 2400MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0 x 16
1 slot
M.2 1 slot (PCIE, support form factor: 2242/2280)
Storage
SATA Controller
D1541 / D1521: 6 x SATA3 6Gb/s (4 port from mini SAS, 1 port
supports SATA DOM)
Ethernet
Interface 1000 /100 /10 Mbps
LAN Controller D1521D4I / D1541D4I:
- 2 x RJ45 GLAN by Intel® i210
D1541D4I-2L2T:
- 2 x RJ45 GLAN by Intel® i210
2 x RJ45 10GLAN by Intel® X557-AT2
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
