EPYCXXXXD4I-2T / EPYXXXXD4I-NL Series
6 7
English
No. Description
1 Rear Fan Connector (FAN2)
2 Intelligent Platform Management Bus header (IPMB_1)
3 ATX 12V Power Connector (ATX12V1)
4 ATX 4-PIN Power Connector (ATX12V2
(ATX 24pin-to-4pin)
)***
5 PSU SMBus (PSU_SMB1)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_B1, DDR4_B2)*
7 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_A2)*
8 Front Fan Connector (FAN3)
9 CPU Fan Connector (FAN1)
10 OCuLink x4 Connector (OCU1)
11 SATA3 Connector (SATA_4)**
12 SATA3 Connector (SATA_5)
13 SATA SGPIO Connector (SATA_SGPIO1)
14 M.2 Socket (M2_1) (Type 2280/22110)**
15 SATA Power Connector (ATX12V3)***
16 USB 3.2 Gen1 Header (USB3_3_4)
17 System Panel Header (PANEL1)
18 Clear CMOS Pad (CLRMOS1)
19 Auxiliary Panel Header (ITX_AUX_PANEL1)
20 TPM Header (TPM1)
21 COM Port Header (COM1)
*For DIMM installation and conguration instructions, please see p.14 (Installation of Memory Modules
(DIMM)) for more details.
** If M2_1 is occupied by a SATA-type M.2 device, SATA_4 will be disabled.
***Caution: Misconnection between the ATX12V2 and the ATX12V3 connectors may permanently damage the
motherboard.
