EPYCXXXXD4I-2T / EPYXXXXD4I-NL Series
2 3
English
Management
BMC Controller
ASPEED AST2500 : IPMI (Intelligent Platform Management
Interface) 2.0 with ikvm and vMedia support
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management LAN
Features
- Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
Rear Panel I/O
VGA Port D-sub x 1
Lan Port
EPYC3251D4I-2T / EPYC3151D4I-2T / EPYC3101D4I-2T:
- 2 x 10GLAN RJ45(by Intel® X550-AT2 )
EPYC3251D4I-NL / EPYC3101D4I-NL:
N/A
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button 1
USB 3.2 Gen1 2
Internal Connector
COM Header 1
M.2
1 x M-Key (PCIe3.0 x4 or SATAIII 6.0 Gb/s); Supports
22110/2280 form factor
Front Panel 1
Auxiliary Panel
Header
1 (include chassis intrusion, 2 front LAN LED, System LED)
TPM Header 1
IPMB Header 1
PSU_SMB1 1
USB 3.2 Gen1
Header
1 (supports 2 USB 3.2 Gen1 ports)
Fan Header 1 x CPU Fan, 2 x System Fans (1 front, 1 rear)
ATX Power 1 x (4-pin) + 1 x (8-pin) support 12V DC-IN
SATA Power
1 (for DC-IN mode)
*Caution: Misconnection may permanently damage the motherboard.
ClearCMOS 1 (short pad)
FanFail LED 3
SATA SGPIO 1
System BIOS
BIOS Type 16MB AMI UEFI Legal BIOS
