12 13
English
EPYC3251D4I-NL / EPYC3101D4I-NL
CH. A
DDR4 DIMM
1866/2133
w ECC
(2) 288-pin DDR4
U/R/LR DIMM slots
AMD EPYC™
Embedded
3000 Series
4-16 Core
SoC
(SP4/SP4r2)
PCIe3.0 x16
DDR4 DIMM
1866/2133
w ECC
CH. B
DDR4 DIMM
1866/2133
w ECC
(2) 288-pin DDR4
U/R/LR DIMM slots
DDR4 DIMM
1866/2133
w ECC
Slot 7 x16 witch
M.2 M-Key
22110/2280/
1x SATA 3
PCIe 3.0 x4
2x USB 3.1 Gen1/USB 2.0
Rear USB
TPM Header
AST2500
LPC
PCIe x1
Switch
RGMII
UART
VGA
PHY
Mgmt. Port
COM Port
D-sub
BIOS
Flash
1x USB2.0
1x SATA 3
Switch
2x USB 3.1 Gen1
Header
USB
Hub
2x USB2.0
1x USB 2.0
PCIe3.0 x4/4x SATA 3
Oculink 4i
PCIe3.0 x8/8x SATA 3
(2) Oculink 4i
N1
N1: SP4 SKU can support 2 more PCIex4/SATA3 and 1 PCIex4 Oculink
SP4 SKU has total 24 lanes left
