2.5 Installation of Memory Modules (DIMM)

is motherboard provides eight 288-pin DDR4 (Double Data Rate 4) DIMM slots, and

supports Quad Channel Memory Technology.

Quad Channel Memory Conguration

Priority

DDR4_A1

(Blue)

DDR4_A2

(White)

DDR4_B1

(Blue)

DDR4_B2

(White)

1 Populated Populated

2 Populated Populated Populated Populated

Priority

DDR4_C1

(Blue)

DDR4_C2

(White)

DDR4_D1

(Blue)

DDR4_D2

(White)

1 Populated Populated

2 Populated Populated Populated Populated

*Since installing three memory modules is NOT supported on this motherboard, we suggest not using

this conguration.

1. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;

otherwise, this motherboard and DIMM may be damaged.

2. For quad channel conguration, you always need to install identical (the same brand,

speed, size and chip-type) DDR4 DIMMs.

3. It is required to install four memory modules to activate Quad Channel Memory Tech-

nology.

e DIMM only ts in one correct orientation. It will cause permanent damage to the

motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
