Daikin UCJ850N [14/38] Symbols
![Daikin UCJ850N [14/38] Symbols](/views2/1694766/page14/bge.png)
12
UCJ1320P
UCJ1600N
FuR·S
FuU,V
MC
MF
RL
SS
TeS
Th
Tr
VR
WL
Field spply:
AXP
*
2C
2CX,
3X
6C
10
10X
20RS
23A
30FX
30FY
42C
43CH
47
49C
51C
51F
52C
52F
63H
BS
Timing relay ( -왕 Change)
Magnetic relay
Magnetic relay
Magnetic contactor (MC)
Timing relay (5 sec)
Magnetic relay
Solenoid valve (start)
Thermostat
Magnetic relay
Magnetic relay
Magnetic contactor (MC)
Magnetic relay
Reverse phase protector
Compressor thermal protector
Overcurrent relay (MC)
Overcurrent relay (MF)
Magnetic switch (MC)
Magnetic switch (MF)
High pressure switch
Push button switch
Fuse 250V, 5A
Fuse 600V, 3A for UCJ1320P-YE,
5A for UCJ1600N
Motor (Compressor)
Motor (Fan)
Pilot lamp (Operation-Red)
Selector switch
Terminal strip
Thermistor (23A)
Transformer (200VA)
Variable resistor
Pilot lamp (Alarm or emergency-
White)
Auxiliary contact (lnterlock)
Component for remote control
Symbols
Notes:
1. : Terminal of TeS
: Jumper
: Relay board
: Additional wiring for remote control.
2. : The wiring to interlock with condenser water pump.
(Remove the jumper wire between (1) and (2) on TeS
and connect "AXP".)
"AXP" should be supplied separately.
3. The devices shown in are attached outside of the
switch box.
4. Connection of transformer is as follows.
Transformer
5. Function of 23A : Part shows "ON"
Terminals
U-V1
U-V2
U-V3
Primary/Secondary
YE Model
380V/200V
400V/200V
440V/220V
415V/200V
Remarks
Factory connectin
Change connection
on the spot.
Temperature
LH
C1–H1
C1–L1
C2–H2
C2–L2
