Daikin UCJ850N [19/38] Ucj1000p

Daikin UCJ850N [19/38] Ucj1000p
17
150
(0.04)
225
(0.06)
300
(0.08)
Evap. air
AFR
(BF)
EWB
EDB
16.0
18.0
19.0
22.0
24.0
16.0
18.0
19.0
22.0
24.0
16.0
18.0
19.0
22.0
24.0
23.0
25.0
27.0
30.0
32.0
23.0
25.0
27.0
30.0
32.0
23.0
25.0
27.0
30.0
32.0
TC
67.6
72.9
76.1
86.5
95.0
75.1
81.0
84.6
96.2
105.5
80.4
86.7
90.5
102.9
112.9
SHC
49.0
49.1
52.2
52.8
53.4
60.4
60.5
64.8
65.2
65.6
71.0
71.0
76.5
76.7
77.0
WFC
214
230
238
267
290
233
251
261
293
318
248
266
277
311
338
PD
29.1
32.9
35.0
42.9
49.3
33.7
38.5
41.3
50.2
57.4
37.7
42.6
45.7
55.2
64.3
PI
14.3
15.2
15.4
15.9
16.3
14.5
15.3
15.5
16.1
16.5
14.6
15.5
15.7
16.3
16.6
TC
67.2
72.5
75.4
85.8
94.8
74.7
80.6
83.7
95.3
105.3
79.9
86.2
89.6
102.0
112.7
SHC
48.8
49.0
51.9
52.5
53.3
60.2
60.3
64.4
64.8
65.5
70.8
70.8
76.2
76.4
77.0
WFC
216
231
239
268
292
236
253
261
293
320
250
268
277
311
340
PD
29.6
33.2
35.3
43.1
49.9
34.5
39.1
41.3
50.2
58.1
38.3
43.1
45.7
55.2
65.0
PI
15.8
16.2
16.4
17.0
17.4
16.0
16.4
16.6
17.2
17.6
16.1
16.5
16.7
17.3
17.7
TC
66.4
71.6
74.6
85.1
93.3
73.8
79.6
82.9
94.5
103.6
78.9
85.2
88.7
101.1
110.9
SHC
48.4
48.5
51.5
52.2
52.7
59.8
59.9
64.1
64.5
64.9
70.3
70.4
75.8
76.1
76.4
WFC
217
232
240
269
291
237
253
262
294
319
251
268
278
312
338
PD
29.8
33.5
35.6
43.4
49.6
34.8
39.1
41.6
50.6
57.7
38.5
43.1
46.0
55.5
64.3
PI
16.9
17.3
17.5
18.2
18.6
17.1
17.5
17.7
18.4
18.8
17.3
17.7
17.9
18.6
18.9
TC
65.1
70.2
73.1
82.8
91.8
72.3
78.0
81.2
92.0
102.0
77.3
83.5
86.9
98.5
109.1
SHC
47.8
47.9
50.8
51.2
52.1
59.2
59.2
63.4
63.6
64.3
69.7
69.7
75.1
75.2
75.8
WFC
217
231
239
266
291
236
252
261
291
318
250
266
276
308
337
PD
29.8
33.2
35.3
42.6
49.6
34.5
38.8
41.3
49.6
57.4
38.3
42.6
45.4
54.2
63.9
PI
18.0
18.4
18.7
19.3
19.8
18.2
18.6
18.9
19.5
20.0
18.4
18.8
19.1
19.7
20.2
25.0
30.0
35.0 40.0
Leaving condenser water temperature (°C)
Notes:
1.Figures in show nominal capacities.
2.Capacity and condenser water flow rate are based on 5.5°C (10°F) temperature rise. There is
no need to correct capacity, if the temperature rise is within 5~9°C, but compute condenser
water flow rate (WFC') using the following formula.
WFC'WFC
However, limit condenser water flow rate to the range of figures for "Pressure drop through
condenser" shown on page 27.
3. Ratings shown are net capacities which do not include a deduction for evaporator fan
motorheat.
4. SHC is based on each EWB and EDB.
Add SHC to SHC.
SHC Capacity correction for SHC for other dry bulb temp.
0.2960AFR (m
3
/min)(1-BF)(DB-EDB)/860
5. Direct interpolation is permissible. Do not extrapolate.
Symbols:
AFR : Air flow rate (m
3
/min)
BF : Bypass factor
EWB : Entering wet bulb temp. (°CWB)
TC : Total capacity (kW)
SHC : Sensible heat capacity (kW)
WFC : Condenser water flow rate (l/min.)
PD : Pressure drop (kpa)
(Cooling water)
PI : Power input (compressor) (kW)
UCJ850N
