Power supply
SYMBOL
YE
Power supply
3C, 380~415/400~440V, 50/60Hz
(3 wires)
Available model
UCPJ100N
UCPJ170P
UCPJ250P
UCPJ335P
UCJ500P
UCJ670P
UCJ850N
UCJ1000P
UCJ1320P
UCJ1600N
UCJ2000N
3. Standard accessories
1. Operation manual
2. Installation manual
3. Bolts, nuts for duct flange (UC(P)J170~2000)
4. V-pulley for fan motor (UCJ850~2000)
5. V-belt (UCJ850~2000)
4. Optional accessories
* 1. Electric heater (UC(P)J100~670)
2. Hot Water heater
3. Steam heater
4. Evaporating pan type humidifier (UC(P)J100~1600)
5. Steam spray type humidifier
6. Water spray type humidifier
* 7. Fan motor pulley change [Evaporator fan]
* 8. Fan motor 1 size larger [Evaporator fan] (except UCPJ100)
9. Fresh air intake (UC(P)J100~670)
10.Rear suction inlet (UC(P)J100~670)
11.Plenum chamber (UC(P)J170~670)
12.Side discharge grille for plenum chamber (UC(P)J100~670)
13.Pressure gauge (UC(P)J100~670)
14.Condenser water interruption relay
Note: * These options should be attached in DAlKIN factory.
Field modification are not available.
In case ordering these modifications, inform "Air flow rate (m
3
/min)"&"External static pressure (mmH2O)"
