List of Electrical and Functional Parts Si38-606
222 Appendix
∗
only for FXD20~63MVE, FXD20~32PVE (with Drain Pump Type)
Parts Name
Symbol
Model
Remark
FXK
25LVE
FXK
32LVE
FXK
40LVE
FXK
63LVE
Remote
Controller
Wired Remote
Controller
BRC1C62 Option
Wireless Remote
Controller
C/O BRC4C63
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
15W 4P 1
φ
20W 4P 1
φ
45W 4P
Thermal Fuse 146°C
Thermal protector 120°C : OFF 105°C :
ON
Drain Pump M1P
AC 220-240V (50Hz)
PLD-12200DM
Thermal Fuse 145°C
Swing Motor M1S
MP8-L [3PA07312-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-13
φ
4 L630
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7
φ
8 L1600
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-7
φ
6 L1600
20k
Ω
(25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22H21R8
Parts Name Symbol
Model
Remark
FXD
20MVE(T),
PVE(T)
FXD
25MVE(T),
PVE(T)
FXD
32MVE(T),
PVE(T)
FXD
40MVE(T)
FXD
50MVE(T)
FXD
63MVE(T)
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
62W 1
φ
130W
Thermal protector
130°C: OFF, 83°C: ON
Drain Pump M1P
AC220-240V (50Hz)
PLD-12230DM
Thermal Fuse 145°C
∗
Thermistors
Thermistor (Suction Air)
R1T
ST8601-1
φ
4 L=250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-4
φ
8 L=800
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-4
φ
6 L=800
20k
Ω
(25°C)
Others
Float Switch S1L FS-0211E
∗
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22H21R8
