Si38-606 Basic Control
Function 45
2. Basic Control
2.1 Normal Operation
Cooling Operation
Actuator Operation Remarks
Compressor Compressor PI control
Used for high pressure protection control, low
pressure protection control, discharge pipe
temperature protection control, and compressor
operating frequency upper limit control with inverter
protection control.
Outdoor unit fan Cooling fan control
Main motorized valve (EV1) 0 pls
Subcooling motorized valve (EV2) PI control
Hot gas bypass valve (SVP) OFF
This valve turns on with low pressure protection
control.
Oil equalization valve (SVO) ON
In the case of multi-outdoor-unit system, this valve
repeats ON/OFF operation at regular intervals of
time.
Receiver gas charging valve (SVL) OFF
This valve turns on when outdoor temperature is
low.
Receiver gas discharging valve (SVG) OFF
Non-operating unit gas discharging
valve (SVSG)
OFF
Non-operating unit liquid pipe stop valve
(SVSL)
ON
