Specifications Si38-606
26 Specifications
Ceiling Mounted Built-in (Rear Suction Type)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level
difference; 0m. (Heat pump only)
★
4 External static pressure is changeable to change over the connectors inside electrical box, this pressure
means "High static pressure-Standard”.
5 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
★
6 Operation sound is measured in an anechoic chamber.
Model FXYB80KV1 FXYB100KV1 FXYB125KV1
★
1 Cooling Capacity (19.5°CWB)
kcal/h 8,000 10,000 12,500
Btu/h 31,700 39,600 49,500
kW 9.3 11.6 14.5
★
2 Cooling Capacity (19.5°CWB) kW 9.0 11.2 14.0
★
3 Heating Capacity
kcal/h 8,600 10,800 13,800
Btu/h 34,100 42,700 54,600
kW 10.0 12.5 16.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 300×1,400×800 300×1,400×800 300×1,400×800
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.75 3×14×1.75 3×14×1.75
Face Area m² 0.338 0.338 0.338
Fan
Model 3D18H2AH1V1 3D18H2AH1V1 3D18H2AG1V1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 135×1 135×1 225×1
Air Flow Rate (H/L)
m³/min 27/20 27/20 35/24
cfm 953/706 953/706 1,236/847
★
4 External Static
Pressure
Pa 88-49 88-49 88-49
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Piping
Connections
Liquid Pipes mm
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
15.9 (Flare Connection)
φ
19.1 (Flare Connection)
φ
19.1 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Machine Weight (Mass) kg 51 51 52
★
6 Sound Level (H/L) dBA 32/27 32/27 34/27
Safety Devices Thermal Fuse for Fan Motor Thermal Fuse for Fan Motor
Fuse
Thermal Fuse for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-22 : M Series R-22 : M Series R-22 : M Series
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Drawing No. C : 3D023749
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
