Si38-606 Specifications
Specifications 25
Ceiling Mounted Built-in (Rear Suction Type)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level
difference; 0m. (Heat pump only)
★
4 External static pressure is changeable to change over the connectors inside electrical box, this pressure
means "High static pressure-Standard-Low static pressure".
5 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
★
6 Operation sound is measured in an anechoic chamber.
Model FXYB40KV1 FXYB50KV1 FXYB63KV1
★
1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 16,000 19,800 24,900
kW 4.7 5.8 7.3
★
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
★
3 Heating Capacity
kcal/h 4,300 5,400 6,900
Btu/h 17,000 21,500 27,300
kW 5.0 6.3 8.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 300×700×800 300×700×800 300×1,000×800
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.75 3×14×1.75 3×14×1.75
Face Area m² 0.132 0.132 0.221
Fan
Model D18H2AC1V1 D18H2AB1V1 2D18H2AB1V1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 65×1 85×1 125×1
Air Flow Rate (H/L)
m³/min 11.5/9 14/10 19/14
cfm 406/318 494/353 671/494
★
4 External Static
Pressure
Pa 88-49-20 88-49-20 88-49-20
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Machine Weight (Mass) kg 30 31 41
★
6 Sound Level (H/L) dBA 28/24 30/25 32/25
Safety Devices
Fuse
Thermal Protector for Fan Motor
Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-22 : M Series R-22 : M Series R-22 : M Series
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Sealing Pads, Clamps, Fuses,
Screws, Washers.
Drawing No. C : 3D023749
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
