Si38-606 Protection Control
Function 55
4. Protection Control
4.1 High Pressure Protection Control
This high pressure protection control is used to prevent the activation of protection devices due
to abnormal increase of high pressure and to protect compressors against the transient
increase of high pressure.
[In cooling operation]
★
In the case of multi-outdoor-unit system, each outdoor unit performs this control
individually in the following sequence.
High pressure not limited
Pc>2.20MPa
High pressure standby
INV upper limit frequency = 210 Hz
High pressure limited
Pc>2.20MPa
Pc>2.30MPa
Pc<2.04MPa
Pc>2.25MPa
STD compressor
standby for 5 mins
Pc: HP pressure sensor detection
value for each outdoor unit
INV upper limit frequency :
3-step / 10 sec down from
current compressor frequency
INV upper limit frequency:
1-step / 20 sec up from
current compressor frequency
When occurring 3 times within 30
minutes, HPS is activated without high
pressure standby, thus outputting the
malfunction code "E3".
