Field Setting SiBE311209
163 Test Operation
3.2.2 Service Setting
For setting items of (∗1), refer to detailed information provided on P.183 onward.
Setting item Content and objective of setting Overview of setting procedure
Service setting
1
Indoor unit fan
forced H operation
Used to operate the indoor unit in the
stopped state in forced H operation mode.
Set No. 5 of "Setting mode 2" to indoor unit
forced fan H.
2
Indoor unit forced
operation
Used to operate the indoor unit in forced
operation mode.
Set No. 6 of "Setting mode 2" to indoor unit
forced operation mode.
3
Change of target of
evaporating
temperature
(in cooling)
In cooling operation, used to change the
target of evaporating temperature for
compressor capacity control.
Select high side or low side with No. 8 of
"Setting mode 2".
4
Change of target of
condensing
temperature
(in heating)
In heating operation, used to change the
target of condensing temperature for
compressor capacity control.
Select high side or low side with No. 9 of
"Setting mode 2".
5
Setting of defrost
selection
Used to change a temperature at which the
defrost operation is initiated, thus making
the initiation easy or hard.
Select fast side or slow side with No. 10 of
"Setting mode 2".
6
Setting of
sequential startup
Used to start units not in sequence but
simultaneously.
Set No. 11 of "Setting mode 2" to NONE.
7
Emergency
operation (∗1)
If the compressor has a failure, used to
prohibit the operation of compressor(s)
concerned or outdoor unit(s) concerned
and to conduct emergency operation of the
system only with operable compressor(s)
or outdoor unit(s).
Make this setting while in "Setting mode 2".
For system with multiple outdoor units: Set
with No. 38, 39, or 40.
8 Airtight test
Fully open the expansion valves of the
indoor and outdoor units, and energize part
of solenoid valves.
Set No. 21 of "Setting mode 2" to ON.
9
Refrigerant
recovery mode (∗1)
Used to recover refrigerant on site.
With operations of indoor and outdoor units
prohibited, fully open the electronic
expansion valve of the indoor and outdoor
units.
Set No. 21 of "Setting mode 2" to ON.
10
Vacuuming mode
(∗1)
Used to conduct vacuuming on site.
Fully open the electronic expansion valves
of the indoor and outdoor units, and
energize part of solenoid valves. Use a
vacuum pump to conduct vacuuming.
Set No. 21 of "Setting mode 2" to ON.
11
Power transistor
check mode
Used for the troubleshooting of DC
compressors.
Inverter waveform output makes it possible
to judge whether an error results from the
compressor or the PCB.
Set No. 28 of "Setting mode 2" to ON.
12
Setting of model
with spare PCB
In order to replace the PCB by a spare one,
be sure to make model setting.
For this setting, set the DS2-2, -3, and-4
switches on the PCB to the model
concerned.
