SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 282
4.48 Transmission Error between Indoor Units and Outdoor
Units
Remote
Controller
Display
U4
Applicable
Models
All indoor unit models
Outdoor Unit: RTSQ8~16PAY1
Method of Error
Detection
Check if the transmission between indoor unit, outdoor unit and function unit is correctly
executed using micro-computer.
Error Decision
Conditions
When transmission is not carried out normally for a certain amount of time
Supposed
Causes
Indoor to outdoor, outdoor to outdoor relay wiring F1, F2 disconnection, short circuit or
wrong wiring
Outdoor unit power supply is OFF
System address does not match
Defective outdoor unit PCB
Defective indoor unit PCB
