SiBE311209 Specifications
Specifications 12
Notes:
+
1 Indoor temp. : 27°CDB, 19°CWB / Outdoor temp. : 35°CDB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
2 Indoor temp. : 20°CDB / Outdoor temp. : 7°CDB, 6°CWB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
3 Indoor temp. : 20°CDB / Outdoor temp. : -10°CWB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
4 Displacement value are at nominal capacity.
+
5 Motor output are nominal.
Model Name RTSYQ20PAY1
Independent Unit
Outdoor Unit RTSQ8PAY1+RTSQ12PAY1
Function Unit BTSQ20PY1
+
1 Cooling Capacity (19.5°CWB) kW 56.0
+
2 Cooling Capacity (19.0°CWB) kW 63.0
+
3 Heating Capacity kW 56.0
Casing Color Ivory White 5Y7.5/1
Dimensions: (H×W×D) mm (1,680×930×765)×2+(1,570×460×765)
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Displacement
+
4 m³/h 16.9+(13.72+10.53)+16.9
Number of Revolutions r.p.m 7980, (6300, 2900), 7980
Motor Output×Number
of Units
+
5
kW 4.7+(3.5+4.5)+4.7
Starting Method Soft Start
Fan
Type Propeller Fan
Motor Output kW (0.75×1)+(0.75×1)
Airflow Rate m³/min 185+200
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ15.9 C1220T (Brazing Connection)
Suction Gas Pipe mm φ28.6 C1220T (Brazing Connection)
Equalizer pipe mm φ19.1 C1220T (Brazing Connection)
Mass (Weight) kg 205+257+110
Operating Sound dB(A) 63
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 6~100
Refrigerant
Refrigerant Name R-410A
Charge kg 9.4+10.9
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. C: 4D076314
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
