SiBE39-402 Troubleshooting by Indication on the Centralized Remote Controller
Troubleshooting 167
5.5 “MC” Address Duplication, Improper Setting
Remote
Controller
Display
MC
Applicable
Models
Centralized remote controller
Method of
Malfunction
Detection
Malfunction
Decision
Conditions
Supposed
Causes
! Address duplication of centralized remote controller
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Are two or
more centralized
remote controllers
connected?
Disconnect all centralized
remote controllers except one
and reset the power supply of
the centralized remote
controller.
Reset power supply of the
centralized remote controller.
NO
YES
(V2835)
