Specifications SiBE39-402
14 Specifications
Ceiling Mounted Duct Type
Notes: H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m,
level difference: 0m.
H3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m,
level difference; 0m. (Heat pump only)
H4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means "High static pressure-Standard".
H5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colorimetric method (gravity method) 50% or more.
6 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
H7 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of installation conditions.
Model FXMQ80MVE FXMQ100MVE FXMQ125MVE
H1 Cooling Capacity (19.5°CWB)
kcal/h 8,000 10,000 12,500
Btu/h 31,800 39,700 49,600
kW 9.3 11.6 14.5
H2 Cooling Capacity (19.0°CWB) kW 9.0 11.2 14.0
H3 Heating Capacity
kcal/h 8,600 10,800 13,800
Btu/h 34,100 42,700 54,600
kW10.012.516.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 390×720×690 390×1,110×690 390×1,110×690
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×16×2.0 3×16×2.0 3×16×2.0
Face Area m² 0.181 0.319 0.319
Fan
Model D11/2D3AA1VE 2D11/2D3AG1VE 2D11/2D3AF1VE
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 160×1 270×1 430×1
Air Flow Rate (H/L)
m³/min 19.5/16 29/23 36/29
cfm 688/565 1,024/812 1,271/1,024
External Static Pressure Pa 157/160-108/98 H4 157/172-98/98 H4 191/245-152/172 H4
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter H5 H5 H5
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight kg 45 63 65
H7 Sound Level (H/L) dBA 42/38 43/39 45/42
Safety Devices
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R410A M Series R410A M Series R410A M Series
Standard Accessories
Operation Manual, Installation Manual,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws.
Operation Manual, Installation Manual,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws.
Operation Manual, Installation Manual,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws.
Drawing No. 3D038814
() () ()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
