Biostar B250GT5 Версия 5.x [61/80] Led灯

第二章: 硬件安装 | 19

B250GT6 & B250GT5 & H270GT5

LED灯

下面的LED灯由RACING GT软件控制。请参考3.3章节的软件设置。

1. RGB LED 接头

2. MOSFET散热片LED灯

3. 板载LED灯（x12）
