Biostar Z270GT4 Версия 5.x [41/80] Spanish
![Biostar Z270GT4 Версия 5.x [41/80] Spanish](/views2/1707907/page41/bg29.png)
APPENDIX I: Specicaons in Other Languages | 41
H270GT4 & Z270GT4
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura 1151 para procesador Intel® Core i7 / i5 / i3 / Penum / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95Wa
* Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa INTEL® H270 (H270GT4) / INTEL® Z270 (Z270GT4)
Memoria
Soporta DDR4 2400/2133/1866 Doble Canal
Soporta DDR4 3600(OC) Doble Canal (Z270GT4)
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/8/16 GB DDR4
* DDR4-2400 para la familia de procesadores Intel® Core ™ de 7ª generación
* Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 6x SATA III (6Gb/s) : Soporta AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 (32Gb/s):
Soporta PCIe RAID 0, 1 / Intel® Rapid Storage Technology & Intel® Optane Technology
1x U.2 (32Gb/s):
Soporta PCIe RAID 0, 1 / Intel® Rapid Storage Technology & Intel® Optane Technology
LAN Intel i219V / 1x 10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio ALC892 / Canales Audio de Alta Denición 7.1, Hi-Fi(Front + Rear)
USB
H270GT4 :
INTEL® H270
Ranura 1x USB 3.0 TYPE-C -
(1 en las entrada/salidas posteriores)
Ranura 5x USB 3.0 -
(3 en las entrada/salidas posteriores y 2 por los
distribuidores internos)
Ranura 6x USB 2.0 -
(2 en las entrada/salidas posteriores y 4 por los
distribuidores internos)
Z270GT4 :
INTEL® Z270
Ranura 1x USB 3.0 TYPE-C -
(1 en las entrada/salidas posteriores)
Ranura 5x USB 3.0 -
(3 en las entrada/salidas posteriores y 2 por los
distribuidores internos)
Ranura 6x USB 2.0 -
(2 en las entrada/salidas posteriores y 4 por los
distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 3.0 x1
Ranura 1x PCIe 3.0 x16 (x4)
Ranura 1x PCIe 3.0 x16 (x16)
Panel trasero de E/S
Teclado/ Ratón 1x PS/2
Ranura 1x DP
Ranura 1x HDMI
Ranura 1x VGA
Ranura 1x DVI-D
Ranura 1x USB 3.0 TYPE-C
Ranura 3x USB 3.0
Ranura 2x USB 2.0
Ranura 1x LAN
Socket audio 6x
Conectores en placa
Conector 6x SATA III (6Gb/s)
Ranura 1x U.2 (32Gb/s)
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2 ranuras USB 3.0)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x2
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Thunderbolt 3 x1
Conector Externo S/PDIF x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma ATX, 244 mm x 244 mm
Soporte OS
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
* Windows 7 (32/64 bits) / 8.1 (64 bits) sólo para la familia de procesadores Intel® Core ™ de 6ª
generación
* Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
