第四章:帮助信息 | 37
H270GT4 & Z270GT4
4�6 英特尔® Optane 技术 (由3D XPoint内存供电)
透过英特尔® Optane™技术，您可以完全释放处理器的威力，而不只是运用一小部分
而已。要突破这个瓶颈，则需要更佳的储存记忆体，具备快速、价格实惠、非挥发性的
特色。 英特尔® Optane 技术具有为大数据、高效能运算、虚拟化、储存、云端、游戏
与其他多种应用带来革命性改变的潜力。
性能及优点 :
• 大容量内存数据库
• 快速系统恢复
• 低延迟
• 高耐力
英特尔
® Optane 技术的需求简介：
• 英特尔® Optane 内存或存储。
• 英特尔® 第7代核心中央处理器。
• 在支持英特尔®Optane 技术的端口中安装英特尔®Optane 内存或存储器。（详情
请 参 考 第 4 页）
• 安装英特尔® 快速存储技术驱动程序，并按照说明启用英特尔®Optane 技术。
