44 | APPENDIX I: Specicaons in Other Languages
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura 1151 para procesador Intel® Core i7 / i5 / i3 / Penum / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95Wa
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa INTEL® Z270
Memoria
Soporta DDR4 2400/2133/1867 Doble Canal
Soporta DDR4 2600/2666/2800/3000/3200/3400/3600(XMP) Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/8/16 GB DDR4
*DDR4-2400 para la familia de procesadores Intel® Core ™ de 7ª generación.
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 4x SATA III (6Gb/s) : Soporta AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
Conector 2x SATA III(SATA3_3 - Por ASM1061) (6Gb/s) : Soporta AHCI
1x M.2 (32Gb/s) :
Soporta PCIe RAID 0, 1, 5 / Intel® Rapid Storage Technology & Intel® Optane Technology
2x U.2 (32Gb/s) :
Soporta PCIe RAID 0, 1, 5 / Intel® Rapid Storage Technology & Intel® Optane Technology
LAN
Intel X550AT (10GbE) - (Z270GT9)
100/ 1000 / 2500/ 5000/ 10000 Mb/s auto
negociación, capacidad dúplex Mitad/Completo
Intel i219V
10/ 100/ 1000 Mb/s auto negociación, capacidad
dúplex Mitad/Completo
Códec Audio
ALC1220
Canales Audio de Alta Denición 7.1, Hi-Fi(Front + Rear)
USB
INTEL® Z270:
Ranura 1x USB 3.1 TYPE-C (1 en las entrada/salidas posteriores) / Ranura 1x USB 3.1 TYPE-A (1 en las
entrada/salidas posteriores)
Ranura 4x USB 3.0 (4 en las entrada/salidas posteriores)
Ranura 2x USB 3.0 (2 por los distribuidores internos) : Soporta LIGHTNING CHARGER
Ranura 4x USB 2.0 (4 por los distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 3.0(PEX16_SB_1/3) x16 (x4) : Soporta PCIe RAID 0, 1, 5 / Intel® Rapid Storage Technology &
Intel® Optane Technology
Ranura 2x PCIe 3.0 x16 (x4)
Ranura 1x PCIe 3.0 x16 (x8)
Ranura 1x PCIe 3.0 x16 (x16)
Panel trasero de E/S
Teclado/ Ratón 1x PS/2
Ranura 1x DP
Ranura 2x HDMI (1x HDMI 2.0 / 1x HDMI 1.4b)
Ranura 1x USB 3.1 TYPE-C
Ranura 1x USB 3.1 TYPE-A
Ranura 4x USB 3.0
Ranura 1x LAN
Ranura 1x LAN (10GbE) - (Z270GT9)
Socket audio 5x
Ranura 1x S/PDIF out
Conectores en placa
Conector 6x SATA III (6Gb/s)
Ranura 2x U.2 (32Gb/s)
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2 ranuras USB 3.0)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x2
Conector Venlador Sistema x3
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Rayo 3 x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma ATX, 305 mm x 244 mm
Soporte OS
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
* Windows 7 (32/64 bits) / 8.1 (64 bits) sólo para la familia de procesadores Intel® Core ™ de 6ª
generación
* Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
