20 | 第二章: 硬件安装

指示器

BIOS开机自检代码指示器：

当系统启动时此指示器会显示开机自检代

码。若要获取更多详情，请参考4.3章节的

BIOS开机自检代码。

LED灯

下面的LED灯由RACING GT软件控制。请参考3.3章节的软件设置。

1. RGB LED 接头

2. MOSFET散热片LED灯

3. VIVID 盔甲LED灯

4. 南侨散热片LED灯
