18 | Chapter 2: Hardware installaon

Note

 Beforeyoupoweronthesystem,pleasemakesurethatbothATXPWR1/ATXPWR2/ATXPWR3

connectorshavebeenplugged-in.

 Insucientpowersuppliedtothesystemmayresultininstabilityortheperipheralsnotfunconing

properly.UseofaPSUwithahigherpoweroutputisrecommendedwhenconguringasystemwith

morepower-consumingdevices.

PANEL1: Front Panel Header

This 16-pin header includes Power-on, Reset, HDD LED, Power LED, and speaker connecon.

Pin Assignment Funcon Pin Assignment Funcon

1 +5V

Speaker

Connector

2 N/A

N/A

3 N/A 4 N/A

5 N/A 6 N/A N/A

7 Speaker 8 Power LED (+)

Power

LED

9 HDD LED (+)

Hard drive

LED

10 Power LED (+)

11 HDD LED (-) 12 Power LED (-)

13 Ground

Reset

buon

14 Power buon

Power-on

buon

15 Reset control 16 Ground

SATA1/ 2/ 3: Serial ATA 6.0 Gb/s Connectors

These connectors connect to SATA hard disk drives via SATA cables.

Pin Assignment

1 Ground

2 TX+

3 TX-

4 Ground

5 RX-

6 RX+

7 Ground

Note

 WhenSATA3U/SATA3Lconnectorisoccupied,thePCIE-M2_3slotonlysupportsSATAmode.
