第一章: 主板介绍 | 5
X570GT8
规格
板载接口
6个SATA III接口 (6Gb/s)
2个USB2.0接头(每个接头支持2个USB2.0端口)
2个USB 3.1 Gen1 (5Gb/s)接头(每个接头支持2个USB3.1 Gen1端口)
1个电源接口(4针)
1个电源接口(8针)
1个电源接口(24针)
2个CPU风扇接头
2个系统风扇接头
1个系统风扇接头(南桥散热器风扇接头 : 此连接器仅适用于南桥散热器风扇)
1个前置面板接头
1个前置音频接头
1个清空CMOS数据接头
2个LED接头(12V/5V)
主板尺寸 ATX Form Factor，305 mm x 244 mm
操作系统支持
Windows 10(64bit)
* 如有增加或减少任何OS支持，Biostar保留不预先通知的权利。
