Chapter 2: Hardware installaon | 21

X570GT8

Note

 EnsureproperpinconnecngtoyourLEDdevice,wrongconneconmaydamageyourLEDdeviceor

motherboard.



The12V_LEDconnectorsupportsto5050RGBLEDstripswiththemaximumpowerrangof3A

(12V).



The5V_LEDconnectorsupportsupto300LEDsWS2818BindividuallyAddressableRGBLEDstrips

withthemaximumpowerrangof3A(5V).



PleaseusetheVividLEDDJsowaretocontroltheLEDs.Fordetailedsowaresenginformaon,

refertochapter3.3.

2.8 Buttons, Indicators, LEDs

On-Board Buons

CLR_CMOS_BTN:

Press the buon 1~2 seconds to load the BIOS defaults.

Reset:

Touch this buon to reboot the system.

Power:

Touch this buon to turn-on/o the system.

Note

 CannotuseCLR_CMOS_BTNbuonifthepowersupplyiso.

Indicators

BIOS POST Code Indicator: The indicator will

show POST Code while boong. Please refer

to Chapter 4.3 for all the BIOS POST codes.
