22 | Chapter 2: Hardware installaon

LEDs

Below LEDs are controlled by RACING GT EVO program. Please refer to Chapter 3.3 for more

detail soware seng.

1. RGB LED Device Header (5V/12V)

2. Racing ARMOR LED
