Biostar X570GT8 Версия 5.x [5/98] Chapter 1 introduction 5

Chapter 1: Introducon | 5

X570GT8

Specicaons

Internal I/Os

6x SATA III (6.0Gb/s) Connector

2x USB 2.0 Header (each header supports 2 USB 2.0 ports)

2x USB 3.1 Gen1 (5Gb/s) Header (each header supports 2 USB 3.1 Gen1 ports)

1x 4-Pin Power Connector

1x 8-Pin Power Connector

1x 24-Pin Power Connector

2x CPU Fan Connector

2x System Fan Connector

1x System Fan Connector (Southbridge Heatsink Fan Header : This connector is only available for

Southbridge Heatsink Fan.)

1x Front Panel Header

1x Front Audio Header

1x Clear CMOS Header

2x LED Header (12V/ 5V)

Form Factor ATX Form Factor, 305 mm x 244 mm

OS Support

Windows 10(64bit)

Biostar reserves the right to add or remove support for any OS with or without noce.
