APPENDIX I: Specicaons in Other Languages | 53
X570GT8
คุณสมบัติ
พอร์ต I/O ด้านใน
6x SATA III (6Gb/s) พอร์ตเชื่อมต่อ
2x USB 2.0 พอร์ตเชื่อมต่อ (หัวเชื่อมต่อทุกตัวรองรับ 2 พอร์ต USB 2.0)
2x USB 3.1 Gen1 (5Gb/s) พอร์ตเชื่อมต่อ (หัวเชื่อมต่อทุกตัวรองรับ 2 พอร์ต USB 3.1 Gen1)
1x 4-Pin Power พอร์ตเชื่อมต่อ
1x 8-Pin Power พอร์ตเชื่อมต่อ
1x 24-Pin Power พอร์ตเชื่อมต่อ
2x พอร์ตเชื่อมต่อ CPU Fan
2x พอร์ตเชื่อมต่อระบบ Fan
1x พอร์ตเชื่อมต่อระบบ Fan (คอนเนคเตอร์พัดลม Southbridge Heatsink :
คอนเนคเตอร์นี้ใช้ได้สำาหรับพัดลม Southbridge Heatsink เท่านั้น)
1x พอร์ตเชื่อมแต่แผงด้านหน้า
1x พอร์ตเชื่อมต่อออดิโอด้านหน้า
1x พอร์ต Clear CMOS
2x พอร์ต LED (12V/5V)
รูปแบบจากโรงงาน ขนาน ATX จากโรงงาน, 244มม. x 305มม.
สนับสนุน OS
Windows 10(64bit)
Biostar ขอสงวนสิทธิ์ในการเพิ่มหรือถอดการสนับสนุนสำาหรับระบบปฏิบัติการ OS ต่างๆ
โดยไม่ต้องแจ้งให้ทราบล่วงหน้า
