What Service Checker Can Do SiE30-408
134 Service Checker Type3 Application Edition
Procedure Register the system.
Select menu “For a new customer” or “For a project with Customer Name registered”.
A registered system is displayed
here.
Select the system from thisbox.
For a project with Customer Name
registered
If there isany system previously
registered, click on the “OK”
button to select the system.
In order to record a new system,
click on the “NEW”button.
Enter the system name registration.
To use DIII-NET (F1, F2 entry), check the DIII-NET.
