TRACO POWER TIS300-124 [10/12] Industrial power supplies
![TRACO POWER TIS300-124 [10/12] Industrial power supplies](/views2/1709236/page10/bga.png)
http://www.tracopower.com Page 10 of 12
6.8
(0.27)
177.2
(6.98)
82.8
(3.26)
32
(1.26)
120.2
(4.73)
82.6
(3.25)
179
(7.05)
243
(9.57)
TIS 600-124
Input
115/230 VAC 50/60Hz
10,5/6,4 A
N
L
24 VDC / 20 A
Output
+
–
Industrial
Power Supply
Model
+
–
Outline Dimensions mm (inches)
Industrial Power Supplies
TIS Series 50–600 Watt
TIS 600 models
Weight: 2.0 kg (4.41 lb)
Dimensions in [mm], () = Inch
Tolerances: ±0.5 (±0.02)
TIS PLUG-6-RED
Connector Set for TIS 600-1xx RED
TIS PLUG-6-UDS
Connector Set for TIS 600-1xx UDS
Connectors ( Included in shipment)
