TRACO POWER TIS300-124 [9/12] Industrial power supplies
![TRACO POWER TIS300-124 [9/12] Industrial power supplies](/views2/1709236/page9/bg9.png)
http://www.tracopower.com Page 9 of 12
114.6
(4.51)
10
(0.39)
83
(3.27)
38.5
(1.52)
130
(5.12)
83
(3.27)
207
(8.15)
91.5
(3.6)
(1.36)
34.5
34
(1.34)
5
(0.2)
39.5
(1.56)
TIS300-172
Input
115/230 50/60Hz
5,4/3,3 A
N
L
72 VDC / 4 A
Output
+
–
Industrial
Power Supply
Model
DC-ON
+
–
83
(3.27)
130
(5.12)
220
(8.66)
130
(5.12)
46
(1.81)
10
(0.39)
(0.2)
94
(3.7)
41.5
(1.63)
5
47
(1.85)
TIS 500-124-230
Input
230 VAC 50/60Hz
5,3 A
N
L
24 VDC / 20 A
Output
+
–
Industrial
Power Supply
Model
DC-ON
+
–
Case Dimensions
Industrial Power Supplies
TIS Series 50–600 Watt
TIS 300 models
Weight: 1.4 kg (3.09 lb)
Weight: 1.9 kg (4.19 lb)
TIS 500 models
Dimensions in [mm], () = Inch
Tolerances: ±0.5 (±0.02)
TIS PLUG-3
Connector Set for TIS 300
TIS PLUG-3-RED
Connector Set for TIS 300-1xx RED
TIS PLUG-3-UDS
Connector Set for TIS 300-1xx UDS
TIS PLUG-5
Connector Set for TIS 500
Connectors ( Included in shipment)
