Industrial Power Supplies

TIS Series 50–600 Watt

Input Specifications

Input voltage range TIS 50: 93 – 264 VAC

TIS 75, 150, 300, 600: 93 – 132 VAC / 187 – 264 VAC

TIS 500 -124-230. 187 – 264 VAC

TIS 500-124-115: 93 – 132 VAC

Input frequency 47 – 63 Hz

Input current at full load (typ.) at 115 VAC at 230 VAC

TIS 50: 0.85 A 0.50 A

TIS 75: 1.3 A 0.75 A

TIS 150: 2.7 A 1.6 A

TIS 300: 4.9 A 2.9 A

TIS 500: 6.0 A 4.3 A

TIS 600: 7.0 A 5.0 A

Recommended circuit breaker, TIS 50: 5.0 A

characteristic C TIS 75: 5.0 A

or fuse, slow blow typ TIS 150: 10.0 A

TIS 300: 15.0 A

TIS 500: 15.0 A

TIS 600: 20.0 A

Output Specifications

Output voltage adj. range 12 VDC models: 12 – 14 VDC

24 VDC models: 24 – 28 VDC

48 VDC models: 48 – 52 VDC

72 VDC models: 60 – 76 VDC

Regulation – Input variation 0.2 %

– Load variation (10–90%) TIS 50, TIS 75, TIS 150: 1.0 %

TIS 300, TIS 500, TIS 600:

0.3 %

(2.0 % in parallel operation)

Ripple and noise (20MHz bandwidth) <50 mV pk-pk

Electronic short circuit protection current limitation at 110 % typ.

(constant current, automatic restart)

Over voltage protection, trigger point at 140 % typ. Vout nom.

Hold-up time 115 VAC 230 VAC

TIS 50 ... TIS 300: min. 25 ms min. 30 ms

TIS 500: min. 20 ms min. 40 ms

TIS 600: min. 15 ms min. 25 ms
