http://www.tracopower.com Page 11 of 12
Optional Mounting Systems
Industrial Power Supplies
TIS Series 50–600 Watt
Wall mounting kit
B
A
C
7.5
(0.30)
D
E
4.6 (0.18)
TIS 75
MK-75
37 (1.46) 14.5 (0.57) – 134.5 (5.30) 150.5 (5.93)
TIS 150
MK-150
132 (5.20) 13.5 (0.53) 105 (4.13) 134.5 (5.30) 150.5 (5.93)
TIS 300
MK-300
132 (5.20) 13.5 (0.53) 105 (4.13) 134.5 (5.30) 150.5 (5.93)
TIS 500
MK-500
132 (5.20) 13.5 (0.53) 105 (4.13) 134.5 (5.30) 150.5 (5.93)
TIS 600
MK-600
190 (7.48) 37.5 (1.48) 115 (4.53) 197.0 (7.76) 207.0 (8.15)
Models Order code A B C D E
Rugged DIN-Rail mounting kit
4.2
(0.17)
25
(0.98
)
50.1
(1.97)
A
B
C
countersink M4
TIS 150 RMK-150 150 (5.91) 115 (4.53) 35 (1.38)
TIS 300 RMK-300 200 (7.87) 165 (6.50) 35 (1.38)
TIS 500 RMK-300 200 (7.87) 165 (6.50) 35 (1.38)
TIS 600 standard 180 (7.09) 165 (6.50) 15 (0.59)
Models Order code A B C
Dimensions in [mm], () = Inch
Tolerances: ±0.5 (±0.02)
