http://www.tracopower.com Page 8 of 12
100.0
(3.94)
75
(2.95)
37.5
(1.48)
74.0
(2.91)
56.7
(2.23)
26
(1.02)
5
(0.2)
31.5
(1.24)
10
(0.39)
TIS 50-112
Input
115/230 VAC
1,2/0,7 A
N
L
12 VDC
3,5 A
Output
+
–
Industrial
Power Supply
Model
DC-ON
adj
114.6 (4.51)
90
(3.54)
45 (1.77)
10
(0.39)
56.7
(2.23)
86.5
(3.4)
34
(1.34)
5
(0.2)
39.5
(1.56)
TIS 75-112
Input
115/230 VAC
1,7/0,9 A
N
L
12 VDC
6 A
Output
+
–
Industrial
Power Supply
Model
DC-ON
adj
114.6
(4.51)
10
(0.39)
56.7
(2.23)
157
(6.18)
80
(3.15)
38.5
(1.52)
86.5
(3.4)
34
(1.34)
5
(0.2)
39.5
(1.56)
TIS 150-124
Input
115/230 50/60Hz
3,7/1,7 A
N
L
24 VDC / 6 A
Output
+
–
Industrial
Power Supply
Model
DC-ON
Case Dimensions
Industrial Power Supplies
TIS Series 50–600 Watt
TIS 50 models TIS 75 models
Weight: 0.48 kg (1.06 lb)
Weight: 0.80 kg (1.76 lb)
TIS 150 models
Weight: 0.41 kg (0.9 lb)
Dimensions in [mm], () = Inch
Tolerances: ±0.5 (±0.02)
TIS PLUG-1
Connector Set for TIS 50/ 75/ 150
TIS PLUG-1-RED
Connector Set for TIS 150-1xx RED
Connectors ( Included in shipment)
