A75MH / A55MH
33
A75MH A55MH
Onboard-Ans
chluss
SATA3-Anschluss x6 SATA2-Anschluss x6
Fronttafelanschluss x1 Fronttafelanschluss x1
Front-Audioanschluss x1 Front-Audioanschluss x1
S/PDIF- Ausgangsanschluss x1 S/PDIF- Ausgangsanschluss x1
CPU-Lüfter-Sockel x1 CPU-Lüfter-Sockel x1
System-Lüfter-Sockel x1 System-Lüfter-Sockel x1
"CMOS löschen"-Sockel x1 "CMOS löschen"-Sockel x1
USB 2.0-Anschluss x2 USB 2.0-Anschluss x2
USB 3.0-Anschluss x1 N/A
Stromanschluss (24-polig) x1 Stromanschluss (24-polig) x1
Stromanschluss (4-polig ) x1 Stromanschluss (4-polig ) x1
Verbraucher-IR Anschluss x1 Verbraucher-IR Anschluss x1
Druckeranschluss Anschluss x1 Druckeranschluss Anschluss x1
Serieller Anschluss x1 Serieller Anschluss x1
Rückseiten-E
/A
PS/2-Tastatur / Maus x1
HDMI-Anschluss x1
VGA-Anschluss x1
DVI-D-Anschluss x1
LAN-Anschluss x1
USB 2.0-Anschluss x2
USB 3.0-Anschluss x2
Audioanschluss x3
PS/2-Tastatur / Maus x1
HDMI-Anschluss x1
VGA-Anschluss x1
DVI-D-Anschluss x1
LAN-Anschluss x1
USB 2.0-Anschluss x4
Audioanschluss x3
Platinengröß
e
200 mm (B) X 244 mm (L) 200 mm (B) X 244 mm (L)
Sonderfunkti
onen
Unterstützt RAID 0 / 1 / 10 Unterstützt RAID 0 / 1 / 10
OS-Unterstü
tzung
Windows XP / Vista / 7
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
Windows XP / Vista / 7
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
