Motherboard Manual
48
JAPANESE
A75MH A55MH
CPU
Socket FM1
AMD A-Series / E2-Series プロセッサ
AMD 64アーキテクチャでは、32ビットと64ビット計
算が可能です
Socket FM1
AMD A-Series / E2-Series プロセッサ
AMD 64アーキテクチャでは、32ビットと64ビット計
算が可能です
チップセッ
ト
AMD A75 AMD A55
メインメモ
リ
DDR3 DIMMスロット x 2
最大メモリ容量16GB
各DIMMは 512MB & 1GB/2GB/4GB/8GB DDR3
をサポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800/1066/1333/1600/1866 をサポート
登録済みDIMMとECC DIMMはサポートされません
DDR3 DIMMスロット x 2
最大メモリ容量16GB
各DIMMは 512MB & 1GB/2GB/4GB/8GB DDR3
をサポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800/1066/1333/1600/1866 をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE 8728
もっとも一般に使用されるレガシーSuper I/O機能を
採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ITEの「スマートガーディアン」機能
ITE 8728
もっとも一般に使用されるレガシーSuper I/O機能を
採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ITEの「スマートガーディアン」機能
SATA3/
SATA2
統合シリアルATA コントローラ
最高6Gb/秒のデータ転送速度
SATAバージョン3.0仕様に準拠。
統合シリアルATA コントローラ
最高3Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN
Realtek RTL 8111E/8111F
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
Realtek RTL 8111E/8111F
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
HDオーディ
オのサポー
ト
VT1708B/ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
VT1708B/ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
USB3.0
A75 N/A
スロット
PCI Express Gen2 x16スロット x1 PCI Express Gen2 x16スロット x1
PCI Express Gen2 x1スロット x2 PCI Express Gen2 x1スロット x2
PCIスロット x1 PCIスロット x1
